Cutter jaw (double) U

Part number	Name	QTY	Remarks
3363120522	Cutter jaw (double) U	1
3363086479	CUTTER BLADE	2
3360106100	ALLEN SCREW	4
3361850748	LOCK WASHER	4
3363035107	LOCK RING	4
3363120349	Bearing bush	1
3363120345	Bearing bush	1
3363098968	TIP OF TOOTH	2
3363098934	HEXAGON NUT	2
3363123492	HEXAGON HEAD BOLT	2
3363120350	Wear ring	4
3360209834	GREASE NIPPLE	2
3363087600	CAP	2
3362268751	LABEL TIGHTENING TORQUE	2
3363120533	Spacer ring	2
3363120532	Spacer ring	2	1.0 mm (0.04 in.) thick, as required
3363088149	SHIM	2
3363087607	SHIM	2	1.0 mm (0.04 in.) thick, as required
