Tightening torques
| # | Part number | Name | QTY | Remarks | ||
|---|---|---|---|---|---|---|
| - | SCREW HATCON - 22 Nm (16 ft lbf) | 1 | ||||
| - | ALLEN SCREW - 255 + 30 Nm (188 + 22 ft lbf) | 1 | ||||
| - | ALLEN SCREW -180 + 20 Nm (133 + 15 ft lbf) | 1 | ||||
| - | Allen screw - 100 + 10 Nm (74 + 7 ft lbf) | 1 | ||||
| - | ALLEN SCREW - 44 + 5 Nm (32 + 4 ft lbf) | 1 | ||||
| - | ALLEN SCREW - 70 + 10 Nm (52 + 7 ft lbf) | 1 | ||||
| - | HEXAGON HEAD SCREW - 650 + 50 Nm (479 + 37 ft lbf) | 1 | ||||
| - | ALLEN SCREW - 530 + 30 Nm (391 + 22 ft lbf) | 1 | ||||
| - | GREASE NIPPLE - 8 + 2 Nm (6 + 1 ft lbf) | 1 | ||||
| - | ALLEN SCREW - 180 + 20 Nm (133 + 15 ft lbf) | 1 | ||||
| - | ALLEN SCREW - 19 + 5 Nm (14 + 4 ft lbf) | 1 | ||||
| - | Hexagon head screw - 255 + 30 Nm (188 + 22 ft lbf) | 1 | ||||
| - | SCREW HATCON - 22 Nm (16 ft lbf) | 1 | ||||
| - | Hexagon head screw - 70 + 5 Nm (52 + 4 ft lbf) | 1 | ||||
| - | SCREW HATCON - 22 Nm (16 ft lbf) | 1 | ||||
| - | Fitting - 70 + 5 Nm (52 + 4 ft lbf) | 1 | ||||
| - | Fitting - 70 + 5 Nm (52 + 4 ft lbf) | 1 | ||||
| - | Fitting - 150 + 20 Nm (111 + 15 ft lbf) | 1 | ||||
| - | Threaded plug - 25 + 5 Nm (18 + 4 ft lbf) | 1 | ||||
| - | Hexagon head screw - 75 + 10 Nm (55 + 7 ft lbf) | 1 | ||||
| - | Threaded plug - 40 + 5 Nm (30 + 4 ft lbf) | 1 | ||||
| - | ALLEN SCREW - 25 Nm (18 ft lbf) | 1 | ||||
| - | SCREW HATCON - 22 Nm (16 ft lbf) | 1 |
