Mechanical
Spare Parts
Tightening torques
| # | Part number | Name | QTY | Remarks | ||
|---|---|---|---|---|---|---|
| - | HEXAGON HEAD SCREW - 370 Nm (273 ft lbf) | 8 | ||||
| - | HEXAGON HEAD SCREW - 180 Nm (133 ft lbf) | 8 | ||||
| - | HEXAGON HEAD SCREW - 550 Nm (406 ft lbf) | 10 | ||||
| - | NON RETURN VALVE - 200 Nm (148 ft lbf) | 1 | ||||
| - | GREASE NIPPLE - 30 Nm (22 ft lbf) | 1 | ||||
| - | Plug - 30 Nm, use LOCTITE®243 | 9 | ||||
| - | PRESSURE RELIEF VALVE - 80 Nm (59 ft lbf) | 1 | ||||
| - | CHECK VALVE - 80 Nm (59 ft lbf) | 1 | ||||
| - | PLUG - 20 Nm (15 ft lbf) | 1 | ||||
| - | VALVE - 30 Nm (22 ft lbf) | 1 | ||||
| - | VALVE COVER - 2000 Nm (1475 ft lbf) | 1 | ||||
| - | PLUG - 80 Nm (59 ft lbf) | 4 | ||||
| - | Nut - 1385 Nm, use Molykote® | 9 |
