Mechanical
Spare Parts
Bucket without intermediate plate
| # | Part number | Name | QTY | Remarks | ||
|---|---|---|---|---|---|---|
| 3363118389 | Gear cover | 1 | ||||
| 3363118386 | Allen screw | 8 | ||||
| 3361333703 | LOCK WASHER | 8 | ||||
| 3363118400 | Main timing belt | 1 | ||||
| 3363118401 | Secondary timing belt | 2 | ||||
| 3363118402 | Gear | 2 | ||||
| 3363118403 | Washer | 2 | ||||
| 3363118404 | Hydraulic motor | 2 | ||||
| 3363118405 | Seal kit (Hydraulic motor) | 2 | ||||
| 3362328039 | ALLEN SCREW | 8 | ||||
| 3361850596 | PAIR OF LOCK WASHERS | 20 | ||||
| 3360995664 | FLANGE HALF | 12 | ||||
| 3363118433 | Allen screw | 24 | ||||
| 3363118434 | Allen screw | 12 | ||||
| 3363118407 | Washer | 4 | ||||
| 3363125236 | Flow valve | 1 | Working valve block | |||
| 3363118409 | Valve block | 1 | Return valve block | |||
| 3363118412 | Pin | 2 | ||||
| 3361850745 | PAIR OF LOCK WASHERS | 24 | ||||
| 3363118415 | Support | 2 | ||||
| 3363091047 | Flat head socket bolt | 2 | ||||
| 3363118416 | Tensioner fork | 2 | ||||
| 3363118417 | Housing | 1 | ||||
| 3363118420 | Locking pin | 2 | ||||
| 3363118422 | Spacer | 8 |
