Mechanical
Spare Parts
| # | Part number | Name | QTY | Remarks | ||
|---|---|---|---|---|---|---|
| 3363124643 | CUTTER JAW, complete | 2 | ||||
| 3363122359 | CUTTER BLADE | 4 | ||||
| 3363070085 | ALLEN SCREW | 8 | ||||
| 3361850748 | PAIR OF LOCK WASHERS | 8 | ||||
| 3363035107 | LOCK RING | 8 | ||||
| 3363121830 | BEARING BUSH | 4 | ||||
| 3363121532 | BEARING BUSH | 2 | ||||
| 3360209834 | GREASE NIPPLE | 4 | ||||
| 3363087600 | CAP | 4 | ||||
| 3363109965 | WEAR RING | 4 | ||||
| 3362268751 | LABEL TIGHTENING TORQUE | 4 | ||||
| 3363122330 | SHIM | 4 | ||||
| 3363122331 | SHIM | 4 | ||||
| 3363109963 | SPACER RING | 4 | 0.5 mm (0.02 in.) thick, as required | |||
| 3363109961 | SPACER RING | 4 |
