Spare Parts
Seal kit
| # | Part number | Name | QTY | Remarks | ||
|---|---|---|---|---|---|---|
| 3382070080 | SEAL KIT | 1 | ||||
| 0663212001 | O-RING | 2 | ||||
| 3315412200 | SCRAPER RING | 1 | ||||
| 0663212002 | O-RING | 1 | ||||
| 0663211999 | O-RING | 1 | ||||
| 0663990045 | SEAL | 9 | ||||
| 0665070175 | PISTON ROD SEAL | 1 | ||||
| 0663212003 | O-RING | 1 | ||||
| 0663910401 | O-RING | 1 | ||||
| 0663903201 | O-RING | 1 | ||||
| 3315280800 | VALVE RUBBER | 1 | ||||
| 0663212000 | O-RING | 1 | ||||
| 3115329002 | SEAL RING | 1 | ||||
| 0663211400 | O-RING | 1 | ||||
| 3315412300 | PLUG | 1 | ||||
| 0663990049 | STIRCOMATIC | 1 | ||||
| 3315411320 | WIPER | 1 | ||||
| 0665070174 | PISTON ROD SEAL | 2 |
