Signs
General Guidelines for Signs
All machine signs must be in the correct locations, clean, and fully legible.
To clean a sign, use only a soft cloth, water, and soap. Do not use gasoline or other harsh solvents.
Replace any missing or damaged signs. Contact your Epiroc representative for new safety signs.
Mandatory Action Signs
Image | Description |
|---|---|
Read the instructions. Incorrect use of the machine may cause personal injury and property damage. Observe the indications given by the warning signs and follow instructions to avoid serious injuries. |
Fire Equipment Signs
Image | Description |
|---|---|
Location of fire extinguisher. | |
Instructions to activate the automatic fire suppression system. | |
Location of firefighting system actuators. |
Machine Data Plate
NOTE
The machine data plate that is installed on the machine varies depending on the type, specification, and territory in which the machine is operated.
The machine data plate contains the serial number (product identification number) for each individual machine, and is required when:
Contacting Epiroc for support
Ordering components or kits
Creating records
Maintaining records
The machine data plate indicates if the machine is CE certified or EAC certified. If no CE or EAC mark is present on the machine data plate, the machine is not CE or EAC certified.
NOTE
The letters CE is an abbreviation for Conformité Européenne which means in conformity with the EC directives. The existence of a CE mark on a product means that the manufacturer or importer certifies that it complies with the European Union (EU) health, environmental, and safety requirements. The CE mark is also a trademark, which means that a CE-marked product can be sold freely within the EU.
NOTE
The letters EAC is an abbreviation for Eurasian Conformity, which means in conformity with the technical regulations of the Eurasian Economic Union (EAEU). The existence of an EAC mark on a product, means that the manufacturer or importer certifies that it complies with the EAEU requirements of the corresponding technical regulations. Furthermore it means that the product has passed all conformity assessment procedures.
Definition of Operating and Gross Machinery Mass
Operating machinery mass: Mass of machine, as configured:
Including a 75-kg operator for machines with cab
Full fuel tank
All other fluid system volumes according to specification
A half-full water tank is included if the machine is equipped with the water mist option.
Gross machinery mass: Maximum mass as approved by Epiroc:
Includes all options
Including a 75-kg operator for machines with cab
Full fuel tank
Full fluid levels
Maximum mass of rods or pipes in carousel or rod holder
Type Designation Signs for Ordering Spare Parts
Type designation signs are posted on the larger components. Always quote the type designation and serial number when ordering spare parts or making inquiries regarding the products. Type designations and serial numbers are also specified in Machines Online (MOL). Spare parts can be ordered from Epiroc.
