Tightening torques

#Part numberNameQTYRemarks
-GREASE NIPPLE - 30 Nm (22 ft lbf)1
-FITTING - 50 Nm (37 ft lbf)1
-FITTING - 130 Nm (96 ft lbf)1
-Lubricant nipple - 30 Nm (22 ft lbf)1
-Hexagon socket screw M12 x 60 mm 10.9 - 97 Nm (72 ft lbf)1
-Fitting G1/2"A, M18 x 1.5, 12L, 24° cone - 130 Nm (96 ft lbf)1
-Screw - 30 Nm (22 ft lbf)1
-Screw - 70 Nm (52 ft lbf)1
-Hexagonal nut - 50 Nm (37 ft lbf)1
-Hydraulic hose - 140 Nm (103 ft lbf)1
-HEXAGON NUT - 97 Nm (72 ft lbf)1
-PLUG - 40 Nm (30 ft lbf)1
-Screw - 30 Nm (22 ft lbf)1
-Screw - 35 Nm (26 ft lbf)1
-Allen screw - 70 Nm (52 ft lbf)1
-FITTING - 130 Nm (96 ft lbf)1
-Fitting G3/8"A, M18 x 1.5, 12L, 24° cone - 80 Nm (59 ft lbf)1
-Allen screw, M12 x 35 mm 12.9 - 120 Nm (89 ft lbf)1
-Fitting - 30 Nm (22 ft lbf)1
-Grease nipple M10 x 1 mm - 30 Nm (22 ft lbf)1
-Allen screw, M12 x 25 mm 12.9 - 97 Nm (72 ft lbf)1
-Hydraulic hose - 50 Nm (37 ft lbf)1
-Hydraulic hose - 80 Nm (59 ft lbf)1
-FITTING - 50 Nm (37 ft lbf)1
-Plug - 30 Nm (22 ft lbf)1
-Hexagon head screw, M8 x 130 mm 10.9 - 30 Nm (22 ft lbf)1
-Hex Head screw M8 x 25 - 20 Nm (15 ft lbf)1
-Allen screw, M20 x 50 mm 12.9 - 600 Nm (443 ft lbf)1
-Plug - 60 Nm (44 ft lbf)1
-SCREW HATCON - 22 Nm (16 ft lbf)1
