Spare Parts
Seal kit
| # | Part number | Name | QTY | Remarks | ||
|---|---|---|---|---|---|---|
| 3382070079 | SEAL KIT | 1 | ||||
| 3315356200 | SCRAPER RING | 1 | ||||
| 0663210498 | O-RING | 4 | ||||
| 3115329002 | SEAL RING | 1 | ||||
| 0663212000 | O-RING | 1 | ||||
| 0663211400 | O-RING | 1 | ||||
| 0664000003 | SEAL RING | 2 | ||||
| 0663990036 | SEAL RING | 2 | ||||
| 0663903201 | O-RING | 1 | ||||
| - | O-RING | 1 | ||||
| 3315336700 | PLUG | 1 | ||||
| 0665909956 | WIPER | 1 | ||||
| 0665070130 | PISTEN ROD SEAL | 1 | ||||
| 0663210494 | O-RING | 7 | ||||
| 0663211516 | O-RING | 1 | ||||
| 0665070129 | PISTON ROD SEAL | 1 | ||||
| 3315280800 | VALVE RUBBER | 1 | ||||
| 0663211444 | O-RING | 2 | ||||
| 0665090014 | SEAL RING | 2 |
